USB Drivers for the DataMate II

Dgsi port devices driver ed Try this quick method first. It should should work with most systems.

Below, we are sharing the links to USB drivers for most of the popular Android device manufacturers like Samsung, LG, Sony, Google, HTC, Motorola, Dell, etc. These USB drivers are safe to use as they are from their respective manufacturers. All the links are valid and official. We recommend you to download the latest USB drivers. Connect your Android device to your computer's USB port. Right-click on Computer from your desktop or Windows Explorer, and select Manage. Select Devices in the left pane. Locate and expand Other device in the right pane. Right-click the device name (such as Nexus S) and select Update Driver Software. This will launch the Hardware Update Wizard. The device you connected to has new features for USB-C that the cable doesn’t support. The device or dongle isn't connected to the correct USB-C port on your PC (or phone). The device or dongle is using an external hub or dock to connect to your PC (or phone). Too many other Alternate Mode devices or dongles are connected to your PC (or phone).

  1. Download and install the most recent software: Check our downloads page for DigiPro2 or DMM.
  2. Download and run the USB Driver Installer: CDM2802_setup.exe.
  3. Connect the DataMate II and switch on. Windows should recognize the device.
  4. If you have problems, please look at the DataMate Communcations FAQ.
Dgsi Port Devices Driver

Multi-Part Setup

This multipart setup should not be necessary for most systems. .

Part 1: Installing the Digitilt DataMate USB Driver

  1. Turn on your computer.
  2. Connect the DataMate to your computer.
  3. Switch the DataMate on.
  4. The hardware wizard appears. If the hardware wizard does not appear, see instructions at the bottom of the page.
  5. The hardware wizards asks: Can Windows connect to Windows Update to search for software?
  6. Choose 'No, not this time.'
  7. Click Next.
  1. Windows wants to install software for the Digitilt DataMate II USB.
  2. Choose 'Install from a list or specific location'.
  3. Click Next.
  1. Windows asks you to shoose search and installation options.
  2. Choose 'Don't search. I will choose the driver to install.'
  3. Click Next.
  1. Windows asks you to select the device driver.
  2. Choose the newest driver (by date).
  1. Windows might display a warning.
  2. Choose 'Continue Anyway.'
  1. Windows might ask you to confirm replacement of a language file.
  2. Choose 'Yes.'
  1. Windows completes the installation and displays this screen.
  2. Click Finish.

Part 2: Installing the Digitilt DataMate Virtual Comm Port

  1. Part 2 begins immediately. A wizard appears.
  2. The wizard ask' ' Can Windows connect to Windows Update to search for software?
  3. Choose 'No, not this time.'
  4. Click Next.
  1. Windows wants to install software for the Digitilt DataMate II Virtual Comm Port.
  2. Choose 'Install from a list or specific location'.
  3. Click Next.
  1. Windows asks you to select the device driver.
  2. Choose the newest driver (by date).
  1. Windows might display a warning.
  2. Choose 'Continue Anyway.'
  1. Windows completes the installation and displays this screen.
  2. Click Finish.

Tell DMM or DigiPro2 which Comm Port to use.

  1. Turn on your computer.
  2. Connect the DataMate to your computer.
  3. Switch the DataMate on.
  4. Start DMM/DigiPro2.
  5. Choose DataMate - Options
  1. Choose a Comm Port from the list. Try the highest number first. DMM and DigiPro2 will remember this port.
  2. Click OK.
  3. Now your PC and DMM/DigiPro2 are ready to communicate with the DataMate.

If the Wizard does not appear..

You must start the wizard manually.
  1. Connect the DataMate to the PC. Switch it on.
  2. Click Start.
  3. Click Run.
  4. Enter devmgmt.msc and click OK. This opens the device manager.
  5. One driver should be listed in 'Ports.' The other driver should be listed in 'Universal Serial Bus controllers'. You might see a yellow warning icon.
  6. Right-click on the driver.
  1. Right-click on each driver (one at a time).
  2. Choose 'Update Driver.'
  3. The wizard starts for either step 1 or step 2 above.

Basic Troubleshooting Steps

Dgsi Port Devices Driver Scanner

  1. Are you using up-to-date software? Check our downloads page for DigiPro2.
  2. Check your interface cable. If your DataMate has an I/O socket, you must use a cable that has a DB9 connector. If your DataMate has a USB socket, you must use a cable that has a USB connector. They are not interchangeable.
  3. Can you connect the interface cable to your PC? Most modern PCs have only USB ports. If your cable has a DB9 connector, you must use a serial-to-USB adaptor. If your adapter doesn't work, try downloading a new driver from the manufacturer's website.We currently stock a USB-to-serial adapter from Sabrent. Our part number is 56704018. The most current driver can be downloaded here.
  4. Check that the DataMate displays: 'Waiting for PC.' (Choose Comm on the DataMate menu). When you click retrieve new or retrieve all, the DataMate should display 'Linked to PC.' If you don't see that message, try step 5 below. If you do see that message, but then it returns to 'Waiting for PC,' the cable may be bad.
  5. Check the comm menu in DigiPro 2 and DMM. It shows what comm ports are available. Choose a different port. If you are using a serial-to USB adaptor, try the comm port with the highest number.
  6. The PC software remembers which comm port number was used last. If your DataMates use different cables, they also use different comm ports. The software might remember the 'wrong' comm port number so it can't communicate. Go to the comm menu to select the correct comm port number.

Advanced Troubleshooting Steps

Is your USB Driver working? Here is a simple test.

  1. Switch off the DataMate. You can leave the USB cable connected.
  2. Open the comm menu in DigiPro 2 or DMM. You'll see a list of comm ports. Check their numbers.
  3. Close the comm menu.
  4. Switch on the DataMate (and plug in the USB cable if you disconnected it).
  5. Open the comm menu in DigiPro 2 or DMM. Look at the list. Do you see a new comm port number?
  • If you see a new comm port, use that one with the DataMate.
  • If you don't see a new comm port number, the driver is not working. Follow the steps below.

Identify the problem: USB chip or USB driver?

  1. Open the device manager via the control panel. Or use the command line like this: in Win XP, click Run and enter ' devmgmt.msc.' In Win 7, enter 'devmgmt.msc' in the search field.
  2. The device manager appears. Look for a yellow warning triangle. It is probably labelled 'Other.'
  3. Right click on the item. Choose Properties.
  4. The Properties dialog appears. Choose the 'Details' tab.
  5. At the top of the Details tab, there is a droplist. Click the droplist and choose 'Hardware Ids.'
  6. Two lines of text appear.

Dgsi Port Devices Driver Device

  • If you see 'BE40' embedded in either line, you must update the USB chip in the DataMate. You can find instructions here: Updating the DataMate USB chip.
  • If you see '6001' embedded, you must update the latest USB driver. See below.

Installing the latest USB Driver

  1. Click the Driver Tab.
  2. Click the Update Driver button.
  3. Allow Windows to search the internet and update the driver automatically:
  • Win 7 searches the internet and installs the driver.
  • Win XP shows a dialog. Choose yes to allow a search and click Next. Then choose yes to allow automatic installation, and click Next.
  • If Windows has problems installing this driver, use the alternative method below.

Download hsds driver printer. Alternative method for installing the USB Driver

  1. Download the installer program: CDM21216_Setup.exe.
  2. Run the installer program.

FAQ

Dgsi Port Devices Driver
Question: I need to repair my RS-232 interface cable. Do you have a drawing?
Answer: Use the drawing at right. Wire colors may vary, so they are not listed. You'll have to look at both connectors to identify the wire colors. Note that this cable works only with the original DataMate.
Question: I need to repair my USB interface cable. Do you have a drawing?
Answer: Use the drawing at right. Wire colors may vary, so they are not listed. You'll have to look at both connectors to identify the wire colors. Note that this cable works only with the DataMate II.
